| The Hybrid Resectoscope System from Delta Med Surgical represents the pinnacle of endourological engineering. Designed to streamline operating room inventory, this system eliminates the need for separate monopolar and bipolar towers. Urology departments can seamlessly execute traditional monopolar cutting using glycine or effortlessly transition to advanced bipolar plasma vaporization using standard saline, drastically reducing the risk of TUR syndrome in high-risk patients. Key Performance Features -
Dual-Modality Ergonomic Working Element: Available in both Active (thumb-controlled cutting) and Passive (spring-loaded cutting) configurations. The internal electrical distribution is fully insulated, safely accommodating both high-frequency monopolar and bipolar currents.
-
True Continuous Flow Sheath System: Features an inner and outer sheath assembly (typically 24 Fr / 26 Fr) with a rotating stopcock system. This ensures a perfectly balanced inflow and outflow of irrigation fluid, maintaining a crystal-clear visual field and stable intravesical pressure throughout the procedure.
-
High-Definition Optical Alignment: Designed for seamless integration with premium 0°, 12°, 30°, and 70° wide-angle cystoscopes (4mm diameter). The quick-lock mechanism guarantees rigid alignment, preventing image rotation during aggressive tissue resection.
-
Comprehensive Electrode Portfolio: The set comes complete with quick-fit, color-coded electrodes—including Cutting Loops, Coagulation Rollers, and Ball/Spike Vaporization Electrodes—all treated with a proprietary anti-stick coating to minimize tissue charring.
The Delta Med Surgical Quality Standard Forged from Operating Room Grade German Stainless Steel and ultra-high-grade ceramic insulations, this hybrid set is built to withstand thousands of high-frequency surgical cycles. The sheaths and working element are fully autoclavable (134°C) and chemical-sterilization compatible. Every system is manufactured and validated under strict CE, ISO 13485, and FDA guidelines to guarantee absolute safety in endourology. - Complete Set Configuration
| Component Name | Specification / Size | Primary Function | | Hybrid Working Element | Passive or Active Choice | Smooth, ergonomic electrode excursion | | Inner Sheath | 24 Fr. with Ceramic Tip | Holds electrode; provides direct irrigation | | Outer Sheath | 26 Fr. with Quick-Lock | Facilitates continuous flow drainage | | Standard Obturator | Visual / Deflecting Type | Safe, atraumatic urethral entry | | Monopolar Cutting Loop | 24/26 Fr. Compatible | High-precision tissue slicing | | Bipolar Vaporization Electrode | Plasma Roller / Button | Bloodless tissue ablation in Saline | | High-Frequency Cables | Monopolar & Bipolar Leads | Heavy-duty, leakage-protected power delivery | | Sterilization Basket | Stainless Steel with Silicone Pads | Protects delicate sheaths during autoclaving | -
H1: Hybrid Resectoscope System Complete Instrument Set
-
H2: Seamless Monopolar and Bipolar Transurethral Resection
-
H3: Continuous Flow Engineering for an Unobstructed Visual Field
-
H2: German Steel and Advanced Ceramic Insulation: Built for Maximum Patient Safety
|
